Delivery time: 1 month after order acceptance

・Operating stroke (mm): 32, 2 rotation sensors

・No protrusion on the rear side.

・Twice the long stroke compared to conventional models.

・No interference with wiring or piping.

・3-wire sensor

・Drive source: Air 0.3-0.7MPa

・Rotation time: 0.3-3.0sec/180°

・Rotation torque (P=0.5MPa): 4.7N・m

・Applicable workpiece mass (kg): 5kg

・Operating stroke (mm): 32

・Cylinder diameter (mm) Open: Φ25×3 Closed: Φ32×3

*This product is a standard product from Kondo Seisakusho.
