Delivery time: 1 month after order acceptance

・Cylinder diameter (mm): φ63, operating stroke (mm): 16

・Continuous integral molding allows for a seamless linkless structure that allows for smooth movement.

・Openable cover makes it easy to store cables.

・Fully covered structure with high impact resistance.

・With 3-wire sensor

・Drive source: Air 0.3-0.7MPa

・Rotation time: 0.2-0.8sec/180°

・Rotation torque (P=0.5MPa): 5.7N・m

・Operation stroke (mm): 16

・Cylinder diameter (mm): φ63 ※This product is a standard product from Kondo Manufacturing.
