Delivery time: 1 month after order acceptance

・Cylinder diameter (mm): φ40, operation stroke (mm): 10, main body weight (g): 4,800

・Powerful check CKL is standard equipment, achieving high gripping force and high precision.

・Lightweight and compact design contributes to the miniaturization of peripheral equipment.

・Uses a circular flange that makes it easy to design the joint with the robot.

・Sensor 3-wire type

・Drive source: Air 0.3 to 0.7 MPa

・Turning time: 0.2 to 0.8 sec/180 °

・Turning torque (P=0.5 MPa): 5.7 N ・m

・Operation stroke (mm): 10

・Cylinder diameter (mm): φ40

※This product is a standard product of Kondo .
